| Product Parameter |
Parameter Description |
| Dimensions |
86Lx86Wx27.5H(mm) |
| Standard Structure |
304 stainless steel panel with wiredrawing finish |
| Voltage |
DC12V~24V |
| Current |
≤50mA |
| Output Contact |
NO/NC/COM |
| Mechanical life |
1000,000 tested |
| Operating Temp |
-20℃～50℃ |
| Contact Rating |
1A@30VDC |
| LED Status |
Red: Standby Green : Operation |
| Operating Humidity |
0%~99% |
| Wire color |
Red：+
Black： -
Yellow：NC
White： COM
Green：NO |
| Weight |
0.2kg |
| Certification |
CE-EMC CE-LVD RoHS |
Piezoelectric Design, No Mechanical Fault
LED Transformation ,Advanced Fashion& Technology, Smooth Surface with glass, Beauty Design with high fashion
Special Design for Top Grade Office , Best Choice for Sophisticated group
Warranty Service will be honored if the damage is not caused by human, YLI Provides 1 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service centre.
YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.
