Electric Bolt
首頁  ?  Home  ?  Products  ?  Electric Bolt
There are 42 Similar products,Comparison
Fail safe sturdiness electric bolt is for narrow door
Model:YB-500IN(LED)
YB-500I N(LED) is an all-metal construction electric bolt .suitable for narrow frame doors which is possess with Double protection for loading current. The bolt is made of 304 stainless steel solid bar with 950kg holding force and anti-burglar design. It contains the design of magnetic valve, particular photoelectric control structure
Keywords:
Share to:
Product Parameter Parameter Description
Feature Fail Safe
Face Plate 185Lx25.7Wx37H(mm)
Bolt 16(length)*12.7(diameter)(mm)
Voltage DC12V
Start Current 960mA
Standby Current 180mA
Solid Bolt polishing housing, 1000Kg Holding Force
Suitable For Electric Bolt  For Narrow Door
Signal Output Door status Output,NO/COM
Surface Temp Low Temperature
Induction Distance 8mm
Bolt structure 304 stainless steel
Static strength test approx. 950kg (third-party report)
LED Light on indicates locked, light off indicates unlocked
Special Designed Tested to 500000 operations
Face place material Stainless Steel
Weight 1.2kg
Certification CE-EMC CE-LVD FCC RoHS REACH WEEE
Low Temperature, safe & Durable.
Low Power, Environmental Protection.
Special photoelectricity control,three steps current application.
Long Life  with 500000 cycles.
Superior Strength Aluminium Alloy,Solid Stainless Steel Bolt.
Autolock Time Delay: 0,3,6,9sec.
Door statue signal output contact(NC.COM).
Double protection for loading current.
Auto-relock if no Action within 5 secs.
Photoelectricity Control,Low Temperature,
  A:The  Low Current is Changed immediately;
  B:When door frame doesn`t coincide with door leaf ,door leaf against the bolt,then the electric bolt will start the low-power function to bring low temperature.
  C:The Photoelectricity Control Technology,prevent the machanical defect.


Warranty Service will be honored if the damage is not caused by human, YLI Provides 2 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service center.

YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.

Packing Quantity(PCS/CTN)
Packing Size(L*W*H)(cm)
Gross Weight(KG)

 coming soon
