Electromagnetic Door Holders
There are 17 Similar products,Comparison
Extended Wall Mount Door Holder
Model:YD-602
YD-602 is a Long type wall mount door holder .The low power consuming design, makes it more environment friendly and more durable. Professional anti-residual magnetism design ensures highest security. It will release automatically the fire door when fire alarms. It also contains build-out release button for testing and build-in MOV which reverse current protection.
Keywords:
Share to:
Product Parameter Parameter Description
Dimensions  L80xW80xH103(mm)
Holding Force  70kg(140Lbs)±10%
Voltage   Factory Default:24VDC,12VDC(Adjustment)
Current Draw  12V/140mA     24V/70mA
Optional   Manual door release button
Suitable for  All Kinds of  Single & Double Smokeproof Doors
Signal Output  NO(Green)/NC(Yellow)/COM(White) (YD-602S)
Surface Temp  ≤+20℃
Operating Temp  -10~+55℃(14-131F)
Suitable Humidity  0~90%(relative humidity)
Finishes for Shell  High Temperature Paint and Environmental Protection Zinc
Finishes for Armature  Zinc
Salt spray test 500-hour exposure (National laboratory report)
Weight  1.0kg
Certification CE-EMC FCC  EN1155 EN1634-1
Col linear Load Test 50kg--110pounds.
Dual Voltage 12/24 VDC(Adjustable).
The Standard Voltage is 24VDC when Finished.
MOV Provides Reverse Current Protection.
Low Power,Environmental Protection.
Anti-Residual Magnetism Design.
Professional Design,  Dual Insulate Housing.
Automatically close the smoke proof door when fire happens.
CE Certificate.



Warranty Service will be honored if the damage is not caused by human, YLI Provides 1 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service centre.

YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.

Packing Quantity(PCS/CTN) 15
Packing Size(L*W*H)(cm) 54.5*20*30.5
Gross Weight(KG) 15.6
