| Product Parameter |
Parameter Description |
| Size |
65Lx32Wx13H(mm) |
| Holding Force |
35kg±10% |
| Input Voltage |
DC12V (Customizable DC24V) |
| Current |
200mA |
| Protection Grade |
IP67 |
| Operating Temperature |
-10℃~+50℃(-14~122F) |
| Suitable |
File Cabinet ,Display Cabinet |
| Weight |
0.25KG |
| Certification numbe |
ECM 23 ATEX-B DN 89 |
| ATEX |
II 1G Ex ib IIC T6 Gb
II 2D Ex ib IIIC T85°C /T100°C Db |
| Certification |
CE-EMC、IP66、ATEX |
Collinear Load Test 40kg,88pounds.
MOV Provides Reverse Current Protection.
Anti-Residual Magneism Designed.
High Strength Material,Anodized Aluminum Housing.
Design with no Mechanical Bolt.
Increase the holding Force,Dual Insulative Hosing.
CE Certificate by European Union,MA Certificate by China Public Security Office.
Warranty Service will be honored if the damage is not caused by human, YLI Provides 2 years warranty for relative products. On the contrary, YLI will charge extra if repair. More information, please browse our service center.
YLI Company retains right to modify the specification of products, and for parameters amendment of products, we will not inform in advance. The relative pictures are not allowed to used in any other way without the consent of YLI Company. Meanwhile, we reserved all the rights of law for any tangle.
| Packing Quantity(PCS/CTN) |
18 |
| Packing Size(L*W*H)(cm) |
62*14.5*14.3 |
| Gross Weight(KG) |
8.64 |
